2020-04 Lonesome Dove Trail Drainage Culvert Extension

Engineering Progress

10%


Engineering Phase2020-04Timeline

Construction Phase
2020-04B2Timeline

50.90 D-1      6-Foot by 6-Foot Reinforced Concrete Box Culvert Extension:

Extension of existing 6 foot X 6 foot reinforced concrete box culvert to creek to alleviate open channel erosion - Approx. 250 linear feet

50.91 D-2      18-inch Reinforced Concrete Pipe Culvert:

Extension of existing 18 inch reinforced concrete pipe culvert to creek in order to alleviate open channel erosion - Approx. 225 linear feet

50.92 D-3      18-inch Reinforced Concrete Pipe Culverts:

Extension of existing 60 inch reinforced pipe culvert to creek in order to alleviate open channel erosion - Approx. 250 linear feet

50.92 D-4      18-inch Reinforced Concrete Pipe Culverts:

Extension of existing 60 inch reinforced pipe culvert to creek in order to alleviate open channel erosion - Approx. 300 linear feet

Area Impacted:

Lonesome Dove Trail
